Company Ablity
Techonical Capacity
research and development center:
■ in order to speed up enterprise development, we takethe development path of producing,learning and researching.
■ Own excellent professional design team and strong product design and development capacity, currentily have 82 engineering technicians, including 11senior engineers,23 engineers.
■ Products fully adopt CAD design three dimensional flow field simuation analysis Rotor dynamics and supporting reliability analysis technology ,perfectly achieve performance and security function. Meanwhiile it has feature of keeping long-term, efficient and smooth running under bad condition.
■ Wehave been established test center for design verification to ensure pump's hyaraulic characteristics, reliability of strucre and operating.
Design Analysis:
From 2003 year, our conmpany began to adopt CAD designtechnology,then used USA Concepts, NREC conmpany three dimensional flow field analysis software and Pushbutton CFD hydraulic model analysis software in 2009. Through making three dimensional flow field simulation analysis for first designed pumps, we could ensure pump hydraulic and suction preformance. Testing result proves first desigined hydraulic model could meet design requirement.
We adopt DyRoBS Rotor analysis software toanalyse critical speed of pump rotor and bearing movement in dynamic and static situation.
DyRoBeS Rotor analysis function includes:
1)Lateral vibration analysis of rotating shaft parts.
2)Torsional vibration analysis of rotating shaft parts.
3)Axial vibration analysis of rotating shaft parts.
4)Supporting parts --static deflection and berring stiffness calcilation analysis.
DyRoBeS Rotor analysis technology could efficiently solve pump vibration and noise and offer storng support for security performance design of high-end pump.
Testing System
Pump Testing System:
■ Examination of materrials
□ ingle and Beruk direct-reading spectromenter,
□ Metallographical analysis meter,
□ Stretching and ballistics test facility,
□ X-ray and ultrasonic non-destructive testing equipment, and penentartion testing method
■ Inspection of parts
□ Coordinate measuring machine,
□ Universal length meter,
□ Optical tool microscope
■ Inspection of products
□ Pressure testing system
□ Open performance testing system
Testing Facility:
■ Hydraulic Characteristic Testing
Testing Circuit ----Flow Q ≤20000m³/h
Testing Power:N≤1600KW
Testing Voltage :380V,.6.6KV,10KV
■ Nuclear pump closed test circuit : max capacity 4000m³/h,pressure≤3Mpa, test temperature ≤80℃,max test power 800kw
■ Synchronization project of pre formance test ;NPSHR, vibration ,noise ,temperature rise , motor power and speed
Manufacturing Capacity
Production Capacity and Product Type:
■ 25000 sets per year for all kinds of pump
(Max dismeter :φ1400mm,max capacity 16000m3/h)
■10000 tons per year for non-pump parts including castings Main pumps type.
■ Main products
□ Single stage/multistage centrifugal pumps including submerged pump and deep well pump.
□ XAH, HZ serise single stage chemical pump.
□ HA, HE, AY serise pertrifaction precess pump.
□ Horizontal multistage process pump.
□ Horizotal multistage process pump.
□ Nucear engineering pump including nuclear three levels device water pump. and chiled water circulating pump.
□ Fire fighting pump.
□ thermal power engineering circulation pump
□ sewater desalination preject system pump.
Production Process:
